Zega D480A Drilling Rig

Zega D480A Drilling Rig

Reference Price

$0.00

Drilling depth30,000 mm
Drilling diameter138 - 203 mm
Rock hardnessF=6-20
Tool TypePneumopercussion
Hammers used6’’/7’’
Floating damper adapterThere are
Movement typeCassette
DriveHydraulic
Cassette Capacity4+1
Drill rod length6,000 / 7,000 mm
Drill Rod Diameter102 / 114 / 127 mm
Torque5,600 nm
Rotation speed0-80rpm
Type of arrowSingle
Overall length of the mastChain: 11,500 mm, Cable: 11,000 mm
Feed Progress7,600 mm
Compensatory move1,300 mm
Feeding MethodCable/Chain
Feed forceCable: 34.5 kn, Chain: 40 kn
Lifting forceCable: 67.6 kn, Chain: 50 kn
Max. Mechanism feed speedRope: 0.88 m/s, Chain: 0.9 m/s
Boom AngleUp 42° / Down 20°
Boom AngleRight 27° / Left 6°
Mast Elevation AngleForward 99° / Backward 42°
Mast angleRight 90°/ Left 55°
ManufacturerCummins
ModelQSZ 13
TypeDiesel
Power410 kW
RPM1,900 rpm
Fuel tank1,000 l
BrandZhigao
ModelZGDA 184 III
TypeScrew Air
Performance33 m3/min
Pressure25 bar
Hydraulic volume. oils in the system500 l
Max. working pressure. glavn. Pump28 MPa
Productivity of the main Pump105 ml/rev
Productivity Pump45 ml/rev
Productivity Pump32 ml/rev
Productivity Pump32 ml/rev
TypeDry (water optional)
Performance60 m3/min
Number of filter elements28 pcs
Total filtration area35 m2
Track width350 mm
Ground clearance420 mm
Angles to be overcome25°
Stabilization angle±10°
Max. Movement Speed3 km/h
Traction
